With an experience of 16 years, we are engaged in offering excellent quality Dialyser Reprocessing System. It is extensively used in dispensaries, hospitals and clinics for reprocessing the used dizlyzer for its re-use on the kidney dialysis patient. This system is made available in different specifications to fulfill the demands of our clients. Our dexterous professionals manufacture our offered system in accordance with latest market standards by making use of quality approved raw material. Our esteemed clients can avail this Dialyser Reprocessing System from us at nominal prices.
Features:
-
Automates the dialyzer cleaning
-
Excellent functionality
-
Accuracy and Safety Operation
-
Effective Processing Time
Dialyser Cleansing System - DCS - FS Fully automated dialyser reprocessing system with programmable sequence and timing option allows chemical / disinfectant of user's choice.
Dialyser Test Details
- Leak Test: Blood Leak test and System Integrity test
- Volume Test: Online dynamic volume test. Automatically detects fill of fluid and volume measured.
Reprocessing Time User Selectable timing of different process. Each process can be configured by the user.
User Access and Reports 4 lines x 16 Character LCD
Alarm and Safety Features
- System Integrity Test
- Bundle Volume Test fail
- Pressure Test fail
- Visual Indication for each sequence
- Printer output with time stamp
- Incomplete machine disinfection alarm
Technical Parameters
- Dimension: 31x25x65 cm
- Weight: 35 Kg Table Top
- Input Voltage: 230V + /- 5%, 50 Hz
- Power: 500W
- Leakage Current: <0.1 mA, 220V
- Ambient Temperature: 5-45 Degree Centigrade
- Relative Humidity: 10-80%
Pre - Requisties
- Purity: R.O. Water in accordance with AAAMI/ ANSI standard
- Inlet Pressure: 24 psi - 40 psi
- Inlet Temperature: 10-40 degree Centigrade
- Inlet Flow: 2.5 I/min (Minimum)
- Drainage: Should be at least 1" (2.5 cm) below the machine base
Certification EMI/ EMC certification from Sameer (Govt. of India) that the product meets the IEC 60601-1-2 safety standard.
